InBody570
Pinnacle Performance

Dimension : 20.55(W) x 35.16(L) x 43.82(H) : in
Color : BLACK & WHITE
Display UNIT : 800 X 480 Color 7inch color TFT LCD
Frequency : 5, 50, 500kHz

InBody InBody

InBody

Features

Provides comprehensive muscle and fat diagnosis that are essential in monitoring health
Segmental Muscle/Fat Analysis allows you to clearly understand your muscle/fat distribution and where you need to focus on muscle/fat development
Graphs allow you clearly track your progress through time
World's best technology with upgraded utilization
Easy-to-read and comprehensive results sheets that anyone can understand
Stores every test result which can be opened and printed anytime
Customizable results sheets that allow you to fit your results for your use
Features and design for optimum user convenience
Simple to use administrator menu allows you to configure the device with ease
Large color touchscreen that guides examinees through tests
On-screen body composition interpretations to help explain results

Outputs

Intercellular Water, Extracellular Water, Total Body Water, Dry Lean Mass, Lean Body Mass, Body Fat Mass, Weight, Skeletal Muscle Mass, Body Mass Index, Percent Body Fat, Segmental Lean Analysis (Right Arm, Left Arm, Trunk, Right Leg, Left Leg), Segmental Fat Analysis (Right Arm, Left Arm, Trunk, Right Leg, Left Leg), ECW/TBW, Body Composition History (Weight, Skeletal Muscle Mass, Percent Body Fat, ECW/TBW), Basal Metabolic Rate, Visceral Fat Level, Impedance at each segment/frequency

Results Sheet

InBody_sheet

InBody_sheet

Body Composition Analysis
The body weight is the sum of Body Fat Mass and Lean Body Mass, which is composed of Dry Lean Mass and Total Body Water. Total Body Water is the sum of Intracellular Water and Extracellular Water. Extracellular Water is the total amount of water outside the body's cell. Maintain a balanced body composition to stay healthy.

InBody_sheet

Muscle-Fat Analysis
Compare the bar lengths of Skeletal Muscle Mass and Body Fat Mass. The longer the Skeletal Muscle Mass bar is compared to the Body Fat Mass bar, the stronger the body is. Skeletal Muscle Mass is the amount of muscle attached to the bones. Body Fat Mass is the sum of subcutaneous fat, visceral fat, and fat surrounding muscles. Subcutaneous fat is found beneath the skin, while visceral fat is found surrounding internal organs in the abdomen.

InBody_sheet

Obesity Analysis
Body Mass Index is an index used to determine obesity by using height and weight.
* BMI = Weight/Height²
Percent Body Fat (PBF) is the percentage of body fat compared to body weight.
* PBF=Fat/Weight x 100

InBody_sheet

Segmental Lean Analysis
Evaluates whether the muscles are adequately developed in the body. The top bar shows the comparison of muscle mass to ideal weight while the bottom bar shows that to the current weight.

InBody_sheet

ECW/TBW Analysis
ECW/TBW, the ratio of Extracellular Water to Total Body Water, is an important indicator whether the body water is balanced. If your ECW/TBW is higher than 0.390, please consult your physician.

InBody_sheet

Body Composition History
Track the history of body compositional changes. Take the InBody Test periodically to monitor your progress. Continuously measuring under the same ID allows the InBody to save each test for future comparison. The Body Composition History allows an individual to track the changes in body composition over their most recent eight results (if selecting 'Recent') or a cumulative graph that shows the progress from the first test results to the most recent results (if selecting 'Total').

InBody_sheet

Visceral Fat Level
Visceral Fat Level is an indicator based on the estimated amount of fat surrounding internal organs in the abdomen. Maintain a Visceral Fat Level under 10 to stay healthy.

InBody_sheet

Results Interpretation
Additional explanation for results sheet outputs are listed here. Each facility can customize what is printed out and tailor the outputs and interpretations to their facility’s needs.

lcd

Model Name InBody270 InBody370 InBody570 InBody770 InBodyS10
Frequencies 20, 100 kHz 5, 50, 250 kHz 5, 50, 500 kHz 1, 5, 50, 250,
500, 1000 kHz
1, 5, 50, 250,
500, 1000 kHz
Test Duration ≒ 15 seconds ≒ 45 seconds ≒ 50 seconds 1 minute 90 to 130 seconds
Weight Range 22-551 lbs. 22-551 lbs. 22-551 lbs. 22-595 lbs. 22-551 lbs.
Age Range 3-99 Years 3-99 Years 3-99 Years 3-99 Years 3-99 Years
Height Range 3ft. 1.4in. - 7ft. 2.6in. 3ft. 1.4in. - 7ft. 2.6in. 3ft. 1.4in. - 7ft. 2.6in. 3ft. 1.4in. - 7ft. 2.6in. 3ft. 1.4in. - 7ft. 2.6in.
Database 100,000 Entries 100,000 Entries 100,000 Entries 100,000 Entries 100,000 Entries
Dimensions 14.0x31.3x39.1
(WxLxH):in.
18.1x26.7x40.2
(WxLxH):in.
20.55x35.16x43.82
(WxLxH):in.
20.7x33.6x46.3
(WxLxH):in.
8x12.7x2.1
(WxLxH):in.
Weight 30.9 lbs. 44 lbs. 52.9 lbs. 83.8 lbs. 4.4lbs.
Warranty 1Year Manufacturer's Warranty
Compatible
Printers
Please contact InBody for further details
Additional Features
Portable Model
Stationary Model
Searchable
Database
Accessories
Results Sheets
InBody USB
Thumb Drive
Carrying case
Thermal Printer
Poster
InBody Tissue
Outputs
Weight
Dry Lean Mass
Lean Body Mass
Skeletal Muscle Mass
Segmental Lean
Analysis
Body Fat Mass
Segmental Fat
Analysis
BMI (Body Mass Index)
PBF (Percent Body Fat)
Visceral Fat Area**
Visceral Fat Level
Total Body Water
Intracellular Water
Extracellular Water
ECW/TBW
Segmental Body Water
Analysis**
Segmental ECW/TBW
Analysis**
Segmental ICW Analysis**
Segmental ECW Analysis**
Body-Fat-LBM Control
BMR (Basal
Metabolic Rate)
Leg Lean Mass
TBW/LBM
Whole Body Phase Angle**
Segmental Phase Angle**
Reactance
Impedance of Each
Segment per frequency
Body Water
Composition History**
Body Composition History Outputs
Weight
Skeletal Muscle Mass
Percent Body Fat
ECW/TBW

* Specification is subject to change without prior notice.
** Outputs are only available on the InBody770 Body Water Results Sheet.
